Black-Out Ducting

PVC Polyester Ducting with Steel Wire Helix

ABC Industries’ Black-Out Ducting has a high opacity finish material that helps block the sun’s radiant heat, making it a clear choice for warm weather climates. The flame-resistant material with expanded pitch allows compression down to one-seventh of its total extended length. The PVC/polyester substrate has a steel wire helix that has excellent UV stabilization and mold and mildew inhibitor for rigorous outdoor use, making it a durable PVC ducting hose and flexible duct solution for demanding ventilation applications.

Designed as a high-performance duct hose, this fabric duct delivers dependable airflow while maintaining the flexibility needed for industrial and outdoor ventilation applications.

*Not recommended for aircraft ground support applications

Specs

  • Flame resistant following UL94VTM-O, California Fire Marshal and NFPA701 method two specifications
  • Sewn construction
  • Weight: 16 oz/yd² (542 g/m²)
  • Temperature Range: -20 to 180 F (-29 to 82 C)
  • Wire: Hard-Drawn Steel
  • Length: 15’, 25’ (4.5, 7.5 m)
  • Color: White
  • Standard Pitch:
    • 3“ (7.5 cm) 6” and 7“ (150 and 200 mm) diameters
    • 4” (10 cm) 8” (200 mm) and larger diameters
  • Expanded Pitch: 12“ and larger (300 mm and larger) = 7” (18 cm) Diameter
  • Optional End Finishes: Belt Cuff, Soft Cuff, Wire Rope Coupling
  • Optional Wear Strip: Heavy-Duty Extruded PVC
  • Inside Diameter: 6” – 36” (150 – 900 mm)
