Yellow Black

Three-Ply Insulated Ducting

Our PVC/polyester substrates are built with steel wire helix and sewn construction. Both insulated and non-insulated products are available. This product has excellent UV stabilization with mold and mildew inhibitors for rigorous outdoor use.

*Not recommended for aircraft ground support applications

Specs

  • Compresses down to one-seventh of its total extended length
  • Flame resistant in accordance with UL94VTM-O, California Fire Marshal and NFPA701 method two specifications
  • Fabric Weight:
    • 1399 (Standard Duty): 13 oz/yd² (331 g/m²)
    • 1899 (Heavy Duty): 18 oz/yd² (610 g/m²)
  • Temperature Range: -20 to 180 F (-29 to 82 C)
  • Wire: Hard-Drawn Steel
  • Length: 15′, 25′ (4.5, 7.5 m)
  • Color(s): Black, Blue, Desert Tan, Kelly Green, Olive Drab, Red, White, Yellow
  • Standard Pitch: 3″ (7.5 cm) for 6″ and 7″ (150 and 200 mm) diameters, 4″ (10 cm) for 8″ (200 mm) and larger diameters
  • Expanded Pitch: 7″ (18 cm) for 12″ (300 mm) and larger diameters
  • Optional End Finishes: Belt Cuff, Soft Cuff, Wire Rope Coupling, Screw Clamp, Zipper Cuff
  • Inside Diameter: 6″ – 36″ (150 – 900 mm)
